enLink Zone View - LoRaWAN Environmental Sensor with e-paper display CO2-TVOC
enLink Zone View - LoRaWAN Environmental Sensor with e-paper display CO2-TVOC
Regular price
$550.00 AUD
Regular price
Sale price
$550.00 AUD
Unit price
/
per
Couldn't load pickup availability
Description
The enLink Zone View is a workplace-grade, LoRaWAN-enabled air quality sensor engineered to monitor key environmental factors such as CO₂, VOCs, temperature, humidity, motion, and ambient light. With an easy-to-read e-paper display, it provides real-time insights to building occupants and managers for ensuring healthier indoor conditions.
Built with high-performance sensors and a long-range wireless connection, this battery-powered device supports proactive environmental management in commercial buildings, schools, and healthcare settings. Its elegant design, broad sensing capabilities, and WELL Building Standard® certification make it a modern solution for air quality assurance
Key Features:
- Multi-Parameter Sensing: Monitors CO₂, VOCs, temperature, humidity, light levels, and occupancy (model dependent).
- Wireless Communication: Utilizes LoRaWAN with up to 16 km transmission range for long-distance deployment.
- Display: 2.7” e-paper screen with high readability and near 180° viewing angle.
- Certification: Aligned with WELL Building Standard® for workplace health compliance.
- Power Supply: Operates on 2 × AA 3.6V lithium batteries with 3+ year lifespan.
- Configuration: Supports USB and LoRaWAN downlink setup for flexible installation.
- Design: Stylish, compact enclosure for discreet integration into modern interiors.
- Manufacturing: Designed and built in the UK, ensuring quality and support.
- Subscription-Free: No licensing or ongoing subscription costs required.
Technical Specifications:
| Component Details | |
|---|---|
| Component Type | LoRaWAN Air Quality Sensor |
| Temperature Range | -40°C to +85°C |
| Temperature Accuracy | ±0.2°C (typical) |
| Temperature Repeatability | ±0.1°C |
| Temperature Response Time | 2 seconds (𝜏63%) |
| Humidity Range | 0–100% RH |
| Humidity Accuracy | ±1.8% RH (typical) |
| Humidity Repeatability | ±0.25% |
| Humidity Response Time | 4 seconds (𝜏63%) |
| CO₂ Sensor (Model Dependent) | NDIR, ±(50 ppm + 3%) of reading, 0–10,000 ppm, ANSI/ASHRAE 62.1-2022, RESET grade B, WELL v2, >15 years life |
| VOCs Sensor (Model Dependent) | IAQ Index 0–500, ±1 IAQ index value, ±10% typical variability |
| Light Sensor (Model Dependent) | 0.01–83,000 lux, <4% error, 99% IR rejection |
| Presence / Motion Sensor (Model Dependent) | IR-based, 4m range, 80° field of view |
| Display Size | 2.7” |
| Display Type | a-Si active matrix TFT e-paper |
| Display Resolution | 264 x 176 pixels (117 dpi) |
| Display Viewing Angle | Super wide, near 180° |
| Power Source | 2 × AA 3.6V Lithium batteries |
| Battery Life | 3+ years (usage dependent) |
| Wireless Protocol | LoRaWAN |
| Wireless Frequency | EU868MHz, US915MHz, AU915MHz |
| Wireless Range | Up to 16 km |
| Certifications | CE, FCC, UKCA, ROHS |
| Device Dimensions | 86 × 86 × 25 mm |
Applications
- Office and workplace IAQ monitoring
- Hospitals, clinics, and healthcare environments
- Smart building automation and compliance
- Education environments and classrooms
- Commercial and retail energy optimization
- Monitoring for WELL, RESET, and ASHRAE standard compliance
